 SP600 : Technical Information Page  (5.1.1) .





Product name

Smart Plug

Dimensions

42/42/40 in mm (L/B/H)

Input Voltage

230 V AC, +/-10% , 50Hz

Switching capacity

230VAC, 13A resistive

Standby Power consumption

2.0W (Co-ordinator, Relay Off)

USB Output

5VDC +/-10%, 2A (max

Type

On/Off switching Plug unit with power consumption measurement at AC outlet

terminal. Power socket with Live, Neutral and Ground.

Plug and Socket type

2-Pin EU Schuko plug and Schuko socket

Energy measurement

Report data in KWh

Data reporting rate

Fully configurable from 2s - 4h

Frequency

2405---2480 MHz license-free band,

(Comply with IEEE802.15.4)

Transmission Power

Max +14dBm meet R&TTE regulation Receiving sensitivity -98dBm (Condition

/ Note: PER = 1% PER, 20bytes packet defined by IEEE 802.15.4 Boost mode)

Communication range

Min 40m LOS

Communication protocol

ZigBee Pro with HA 1.2 Profile but also support Simple meter clusters ( SE)

IP Rating

IP30
